Product Description
Three Phase Linear Electric Actuator
Sdtork Electric Actuator type 6000 Series is designed for Linear application for remote control of Globe Valve and Dosing Pump:
- Torque Range: 9000 Kg to 4000 Kgs
- Output Speed Range: 1 to 36.5 mm/sec
Rated Thrust
| Tripping Thrust adjustable
| Maximum starting thrust* | Linear ouput Speed | Actuator Model
| Self / Non self Locking
| Maximum stroke | Motor
| Appr Wt |
Kg
| Kgs
| Kgs | mm/Sec | mm | Kw/Hp | RPM | Reference | Kg |
| 3000 | 900-3000 |
| 1.0 | SD-6000-3000
| SL
| 75
| 0.75/1
| 1400
| SD080433
| 80
|
| 1.5 | SD-6000-3000 | SL | 75 | 0.75/1
| 1400
| SD080433 | 80 |
| 2.0 | SD-6000-3000 | SL | 75 | 0.75/1 | 1400
| SD080433 | 80 |
| 3.0 | SD-6000-3000 | SL | 75 | 0.75/1 | 1400
| SD080433 | 80 |
| 4.0 | SD-6000-3000 | SL | 75 | 0.75/1 | 1400
| SD080433 | 80 |
| 6.0 | SD-6000-3000 | SL | 75 | 0.75/1 | 1400
| SD080433 | 80 |
| 7.0 | SD-6000-3000 | SL | 75 | 0.75/1 | 1400
| SD080433 | 80 |
4500
| 8.0 | SD-6000-3000 | SL | 75 | 2.2/3
| 2800
| SD09L253 | 80 |
| 12.0 | SD-6000-3000 | SL | 75 | 2.2/3
| 2800 | SD09L253 | 80 |
| 14.0 | SD-6000-3000 | SL | 75 | 2.2/3
| 2800 | SD09L253 | 80 |
| 19.0 | SD-6000-3000 | SL | 75 | 2.2/3
| 2800 | SD09L253 | 80 |
| 24.0 | SD-6000-3000 | SL | 75 | 2.2/3
| 2800 | SD09L253 | 80 |
6000
| 27.0 | SD-6000-3000 | SL | 75 | 2.2/3
| 2800 | SD09L253 | 80 |
| 36.5 | SD-6000-3000 | SL | 75 | 2.2/3
| 2800 | SD09L253 | 80 |
| 4000 | 1200-4000 |
| 1.0 | SD-6000-4000 | SL | 100
| 0.75/1
| 1400
| SD080433 | 90 |
| 1.5 | SD-6000-4000 | SL | 100 | 0.75/1
| 1400 | SD080433 | 90 |
| 2.0 | SD-6000-4000 | SL | 100 | 0.75/1
| 1400 | SD080433 | 90 |
| 3.0 | SD-6000-4000 | SL | 100 | 0.75/1
| 1400 | SD080433 | 90 |
| 4.0 | SD-6000-4000 | SL | 100 | 1.5/2
| 1400 | SD09L453 | 90 |
| 6.0 | SD-6000-4000 | SL | 100 | 1.5/2
| 1400 | SD09L453 | 90 |
| 8.0 | SD-6000-4000 | SL | 100 | 2.2/3
| 2800
| SD09L253 | 90 |
| 9.0 | SD-6000-4000 | SL | 100 | 2.2/3
| 2800 | SD09L253 | 90 |
| 12.0
| SD-6000-4000 | SL | 100 | 2.2/3
| 2800 | SD09L253 | 90 |
